Description
Our Multi-Speed Shutter Fan offers great performance, smooth operation, and a totally enclosed UL507 outdoor certified energy efficient motor. Each fan has a built in 9′ cord and switch for “no electrician required” operation.
- Smooth and quiet operation
- Ships fully assembled out of the box
- Attached 9′ pre-wired 115 Volt cord with 3-prong plug for “No Electrician Required” installation. Just plug it in!
- Outdoor rated UL507 certified motor
- Balanced 3 bladed aluminum prop with a zinc plated steel hub
- Chrome guard allows for easy cleaning and meets OSHA 1910.212(a)(5) requirements to mount at any height on inlet side of fan. (When mounted, shutter side should be 7′ above ground.)
- High efficiency aluminum shutters with tie bar to eliminate shutter flapping and opening on windy days
- Energy efficient, totally enclosed, maintenance free, direct drive high efficiency motors have completely sealed ball bearings, covered by a Full Two Year Warranty
- Optional weather hood for exterior shutter side to protect your fan from harsh weather and severe wind
- Made in USA
Specifications
| Part # | Size | HP | Wired Volt | Amps | Hz | Phs | Spd | Rough Opening |
|---|---|---|---|---|---|---|---|---|
| VPES12 | 12″ | 1/30 | 115 | 1.1 | 60 | 1 | 3 | 12 1/2″ x 12 1/2″ |
| VPES16 | 16″ | 1/10 | 115 | 1.5 | 60 | 1 | 3 | 16 1/2″ x 16 1/2″ |
| VPES20 | 20″ | 1/10 | 115 | 1.5 | 60 | 1 | 3 | 20 1/2″ x 20 1/2″ |
| VPES24 | 24″ | 1/8 | 115 | 1.8 | 60 | 1 | 2 | 24 1/2″ x 24 1/2″ |
| Part # | CFM Hi/Low @ .0″ SP |
CFM @ .05″ SP |
CFM/Watt Hi/Low @ .0″ SP |
RPM Hi/Low |
|---|---|---|---|---|
| VPES12 | 1,100/850/550 | 1,045 | 12/11/10 | 1,500/1,350/1,200 |
| VPES16 | 2,950/2,050/1,200 | 2,800 | 15/14/13 | 1,500/1,350/1,200 |
| VPES20 | 4,220/3,250/2,130 | 4,000 | 18/16/14 | 1,570/1,400/1,000 |
| VPES24 | 5,850/3,475 | 5.560 | 20/16 | 1,200/900 |
Additional Information
Multi-Speed ES Shutter Fan Specifications & Installation (PDF)
