1/2″ 37° JIC Braided Stainless Steel Hose
These chemically resistant PTFE braided hoses are a necessity when dealing with harsh chemicals or solvents and high-pressure applications. They provide a uniquely rugged, durable, and chemically resistant combination of Stainless Steel and PTFE by having an inner core of PTFE and protecting that with a braided stainless steel outer sleeve. These hoses have female JIC swivel on each end and they DO NOT require Teflon tape to create a seal and they should always be tightened and untightened using 2 wrenches.
***Note: Do not exceed the specified hose bend radius or the inner PTFE liner will kink and the hose integrity will become compromised and should not be used.
Stainless Steel Hose Technical Data Sheet
Specifications:
| Connection Type(s): | 1/2″ 37° Female JIC Swivel (3/4-16) |
| Liner Material | PTFE (Teflon) |
| Braid Material | 304 Stainless Steel |
| Swivel Material | 304 Stainless Steel |
| Temperature Rating | -65° to 450°F |
| Pressure Rating | 1500 PSI |
| Chemical Resistance | Excellent |
| Max Bend Radius | 5-1/2″ |
